Ladder Reinforcement

Ladder reinforcement is designed to be embedded in the horizontal mortar joints of single-wythe masonry walls. Ladder reinforcement is manufactured in 10’ lengths and consists of 2 parallel and deformed longitudinal wires welded to a perpendicular cross wire spaced 16” O.C.

Outside parallel spacing is approximately 2 inches less than the nominal thickness of the masonry wall.

This product is available from 2” to 14” widths and can be supplied in varying lengths.

All of our products meet the CSA 370 codes.

Please contact us for spec-sheets.
